Automatic Deployments to Kinsta with Branch

Using Bedrock?

Read our guide on setting up Bedrock on Kinsta using Branch.

There’s also a screencast đź“ş if you are more of a visual learner!

» Go to the guide


Branch is a continuous integration and deployment platform, designed to help you automate the building, testing and deployment of your WordPress projects whenever you push to Git.

Branch makes it easy to deploy your code to Kinsta from GitHub, Bitbucket or Gitlab. Simply connect Branch to your Kinsta account using an SSH key and then run Branch’s ready-made build recipe to deploy to the platform with RSync.

This guide will help you create a Branch account, link it to your WordPress project on Kinsta and automate your builds and deployments.

Follow the full step-by-step instructions below, or skip straight to the section you need using one of the following links.

Table of Contents

  1. Sign up to Branch
  2. Set up a New Project on Branch
  3. Connect Branch to Kinsta
  4. Add Build Steps
  5. Build and Deploy a Theme or Plugin to Kinsta
  6. Build and Deploy a Full WordPress Site to Kinsta
  7. Managing Environments
  8. Need Help?

Sign up to Branch

Signing up to Branch is easy and free — all you need is a GitHub, Bitbucket or GitLab account.

Once you have an account, you can do 20 deployments for free every month, with the option to upgrade to a paid plan for unlimited deployments.

Signing up for Branch is free and gives you 20 deployments per month.

To sign up from the Branch homepage:

  1. Select the Git host you would like to use (either GitHub, GitLab or Bitbucket)
  2. After clicking, you will be redirected to your chosen Git host’s website and prompted to log in and authorize Branch to access to your account. Note: it’s important that Branch has access to the organization hosting the project you will be using.
Authorize Branch to access your GitHub account – remember to grant rights to the organization owning the repository you are connecting.

Set up a New Project on Branch

Next, you will be prompted to pick a project. Start entering the name of your chosen project to see a list of matching Git repositories and select the correct one.

You can connect Branch to any Git repository containing a theme, a plugin, a full WordPress site, or any combination of the above.
Start typing to select your Git repository.

After selecting a project, Branch will set up the connection to your Git provider by taking the following steps:

  1. Adding an SSH key associated with the project. This lets Branch clone the repository.
  2. Adding a webhook to the repository. This lets Branch know when there are new commits and pull requests to build.

Once your new Branch project has been created, you will be redirected to the project configuration screen on your Branch dashboard.

This is where you’ll add your build and test steps. This is also where you can add (secret encrypted) variables to your Branch build environment and where you can manage the settings for your project.
When your project has been created, it’s time to add the first build step to your pipeline.

But first you will need to give Branch access to your Kinsta account.

Connect Branch to Kinsta

Give Branch access to your Kinsta account with an SSH key:

  1. Select your project from your Branch dashboard
  2. Click Settings and scroll down to find your project’s SSH key under SSH public key
  3. Click Only show key and copy the entire key to your clipboard
  4. Log in to your Kinsta Dashboard and go to your account settings
  5. Scroll down to the SSH keys section and click Add SSH Key
  6. In the popup modal fill in the following fields:
    1. Label: enter a name for your Branch key
    2. SSH key: paste your SSH key
  7. Click Add SSH key and wait for confirmation that your key has been imported successfully
Paste the Branch project SSH key into the Kinsta dashboard.

Now Branch can connect to your Kinsta account, it’s time to head back into your dashboard to start adding build and test steps to your project.

Add Build Steps

To add a build step:

  1. Click into your project from your Branch dashboard and select Steps
  2. From here, you can start adding your build steps. Scroll down to the section Add your first build step and click Add build step.

You have the choice to either use one of Branch’s built-in build recipes or define your own custom steps.

For common use cases, there are ready-made build recipes. For example, compiling frontend assets with NPM or validating your code with the WordPress Coding Standards.

Common Build Steps

To use an existing build recipe:

  1. In the Build recipes menu browse to find the tool you need
  2. Click Add step to add it to your build steps
Branch comes prepacked with many different build recipes.

Custom Build Steps

To define your own build steps, click Other in the Add a step section and pick Custom. Fill in the following fields and click Add step:

  1. Name: enter a name for your step
  2. Environment: select an environment in which to run the step eg php, node, ssh and so on
  3. Commands: add the commands you want to run in this step

Advanced Options

You may want to run certain steps on specific Git branches only, say if you only want to deploy when pushing to master.

If so, toggle the Advanced options section of the build step and enter the name of the required branch.

Build and Deploy a Theme or Plugin to Kinsta

In this example, we will deploy a plugin from GitHub to Kinsta. The process would be the same if we were deploying a theme, or if we were using Bitbucket or GitLab.

  1. Connect Branch to your Kinsta account
  2. From the Branch dashboard, go into your project and click the Steps tab
  3. Add the steps necessary to build your theme or plugin For example, you might need to run composer install to pull in the PHP dependencies used by your plugin or, if you’re building a theme, you may have some frontend build steps using Node or Gulp. Branch has a number of built-in build recipes for tasks just like these.
    Note: if you’re running npm install, make sure to delete your node_modules directory before attempting to deploy.

    Let’s take the Composer build recipe as an example. To add this as your first build step:
    1. In the Build recipes menu, select the Composer recipe
    2. Click Add step to add it to your build steps
  4. Next, add your deployment step. Branch has a built-in Kinsta recipe that you can use to deploy with rsync. To add this deployment step:
    1. In the Deploy recipes menu select Kinsta
    2. Configure the RSync connection by completing the following fields:
      • Username: You can find your SSH username in your Kinsta dashboard under the settings for your site
      • Host: Your SSH host is available in the site settings
      • Port: Your SSH port number is available in the site settings
      • Files: The * means that we want to deploy all non-hidden files. In most cases you can just leave this as it is – but make sure to delete any files you don’t want to deploy (for example, node_modules if you’re running npm install)
      • Path: You can find the path to your WordPress site on under site settings as well. It looks something like /www/branch_314/public. As an example, to deploy our plugin, the path would be /www/branch_314/public/wp-content/plugins/Cool-Plugin.
      • Advanced options: To assign a build step to a specific Git branch, click on this section and enter the branch name. For example, if you only wanted to deploy when pushing to master, you would type ‘master’ in this field.
The easiest way to deploy to Kinsta is by using Branch’s built-in Kinsta recipe.
Branch’s recipe for deploying with RSync makes it easy to deploy to Kinsta.
  1. Click Add step to add your deploy step
This build pipeline will pull in all the dependencies and deploy to Kinsta.

Your build pipeline is now ready to trigger your first build and deployment.

Triggering Your First Build

There are two ways to do this:

  1. Manually: click Run build on your project’s configuration page. This will trigger a build from the default branch (this is set to ‘master’ unless you change it under Advanced options)
  2. Automatically: push new code to GitHub using Git to automatically trigger a build for that specific commit

For now, let’s trigger a build manually. Clicking Run build will redirect us to the build overview screen, where we can follow the progress of our build.
This build will be picked up by a build bot any second now.

Once the build has finished running, the build steps will turn green and you will be able to see the build logs.
A successful build in Branch is all green.

If you log into your WordPress site on Kinsta, you will be able to see that your plugin has been deployed.

The plugin that Branch just deployed to Kinsta.

Now every time you push a new commit to GitHub, Branch will automatically run your build steps for you and deploy with RSync.

Pull Requests

If you have an open pull request on GitHub while the build is running, this will show as pending.

Pending pull request waiting for Branch to complete a build.

You will be able to merge any pending pull requests once the build has finished.

This pull request was successfully built in Branch.

This is especially useful if you’re using Branch to put new code on a staging site before merging it into your master branch.

Failed Builds

If something goes wrong during any of the build steps, the whole build will be stopped and any incomplete steps will turn red.
A failed build in Branch.

If a build fails, you can check the Build logs to find out the reason why. In the above case, we accidentally wrote ‘plugin’ instead of ‘plugins’ in the file path.

If you have an open pull request, the error will also show up on GitHub.

This pull request failed to build on Branch.

Build and Deploy a Full WordPress Site to Kinsta

You can also use Branch to automatically build and deploy a full WordPress site to Kinsta.

For example, you might keep your entire WordPress site in a Git repository, either by committing core files or by pulling in WordPress core as a dependency using Composer.

To deploy a WordPress site to Kinsta, you can follow the same steps to deploy a plugin or theme to Kinsta.

Note: When configuring your Deploy with RSync build step you will need to will need to provide the path to the WordPress root and not the plugins or themes folder.

Managing Environments

When setting up automated deployment solutions like Branch, it’s a good idea to consider your deployment workflow.

For example, you might want to push your code to a staging or development environment for testing before unleashing it onto your production site.

Branch lets you add different build and deploy steps for different environments, helping to make your deployment process more robust.

Deploying to a Staging Environment

With Kinsta, it’s easy to set up new WordPress sites with a domain name, which can work well as staging environments. Just leave the domain name blank when creating the site to get a domain name.

To deploy to a specific environment, enter the domain name in the Site Name field when configuring the RSync connection as part of your deployment build step.

Deploying to a Production Environment

To complete your deployment pipeline, you could add an additional step to put your code onto your live site.

To do this, add another Deploy with RSync step to your project.

Note: make sure to specify the ‘master’ branch under Advanced options.

Your code changes would then be deployed to your live site every time you merged them into your ‘master’ branch.

Sign up to Branch

Signing up for a Branch account is easy. Just head over to and sign up with GitHub, Bitbucket or GitLab.

» Sign up to Branch

Need Help?

We hope this guide has been helpful, but if you still have any questions or feedback, or if you just want to say ‘hi’, please reach out by clicking the chat icon or by email at Don’t be a stranger!
